The safety and efficacy of the trans-umbilical approach for pyloroplasty in the management of post-acid corrosive gastric outlet obstruction in children



Gastric outlet obstruction (GOO) may follow acid corrosive ingestion. Several surgical techniques have been reported after the failure of endoscopic dilatation. The aim of this study was to evaluate the feasibility and safety of Heinecke-Mikulicz pyloroplasty (HMP) through a circum-umbilical skin incision in children with pyloric stricture after accidental acid corrosive ingestion.


Seven patients were males and 4 were females, their ages ranged from 17 months to 6 years at the time of definitive treatment. The surgery was completed successfully in all patients through the circum-umbilical incision. Vertical extension of skin incision was needed in one patient. The pylorus was grossly affected in 9 patients. Both pylorus and gastric antrum were involved in 2 patients. Nine patients had an excellent postoperative course with the cessation of vomiting and progressive weight gain. One patient developed postoperative recurrent stricture treated by gastrojejunostomy. Another patient with associated esophageal stricture responded to repeated endoscopic dilatation for the esophageal stricture and pyloroplasty for the pyloric stricture. No surgical site infection or wound dehiscence occurred in any patient.


Heinecke-Mikulicz pyloroplasty through a circum-umbilical approach is both feasible and safe in the majority of children with post-acid corrosive GOO. It is associated with satisfactory wound healing and excellent cosmetic outcome. Different techniques are recommended in cases of severe pyloric stricture associated with significant proximal gastric antral scarring.


Accidental corrosive ingestion by children still occurs in some developing countries [1]. Children are more vulnerable to corrosive injury due to the easy availability of corrosive material in the market, lack of parental supervision, and incorrect storage of these chemicals at home [2].

Gastric injury after corrosive ingestion is relatively uncommon as compared to esophageal injury. Gastric outlet obstruction (GOO) is a significant complication of corrosive acid ingestion [3]. In contrast to post-corrosive esophageal injury, limited series reporting the sequel of acid ingestion on the stomach have been published [4,5,6,7,8,9].

It is generally thought that “acid lick the esophagus and bite the pyloric antrum” [9]. However, gastric burns caused by alkali corrosives have been reported recently [4].

Patients with gastric outlet obstruction caused by corrosive ingestion usually require surgical intervention. The type of the surgery depends mostly on the findings during laparotomy [8]. Pyloroplasty and gastrojejunostomy are the most common surgical procedures described in the literature to relieve GOO [10].

In 1986, Tan and Bianchi reported the first use of a circum-umbilical incision to perform a pyloromyotomy for children with hypertrophic pyloric stenosis [11]. Excellent cosmetic results were reported after this approach [12, 13]. During the past decade, this technique and its modifications have been used for treatment of a variety of surgical intra-abdominal diseases [14,15,16,17,18,19,20].

In this study, we investigated the feasibility and safety of Heinecke-Mikulicz pyloroplasty (HMP), through a circum-umbilical skin incision in children with pyloric/antral stricture after accidental acid corrosive ingestion.


This prospective study included 11 patients presented with post-acid corrosive GOO during the period from May 2009 to May 2019.

Inclusion criteria included patients with GOO, who failed to respond to endoscopic dilatation. Children older than 10 years were excluded assuming that the approach will offer limited access after this age.

A data base chart was designed to collect the following data: sex, age at presentation, time between ingestion of corrosive material and hospital admission for surgery, nature of ingested substance, clinical features, diagnostic studies (contrast study and endoscopy), and response to previous trials of endoscopic dilatation, operative details, and postoperative outcome.

The parents or guardian of every patient had been informed about the details, pros, and cons of the operative technique, and a signed informed consent was obtained. Privacy of the participants and confidentiality of the data were maintained. The study was approved by IRB at our institution.

Surgical technique

All patients were operated under general endotracheal anesthesia and antibiotic prophylaxis. A nasogastric tube was inserted; suction of gastric contents and gastric wash with warm normal saline was done. The umbilicus was thoroughly cleansed with povidone-iodine. After standard skin preparation, a semicircular periumbilical incision was made (Fig. 1). A subcutaneous plane was developed for 3–5 cm, the upper midline fascia was identified and exposed approximately one third to one half of the distance from the umbilicus to the xiphoid process, and then peritoneal cavity was opened through a midline vertical fascial incision (Fig. 2).

Fig. 1

Circum-umbilical skin incision

Fig. 2

Midline vertical fascial incision

The pylorus was identified by first mobilizing the omentum with an opened moist sponge that is gently placed into the peritoneal cavity. By mobilizing the omentum, the transverse colon will be easily visualized in the wound. This maneuver brings the gastric antrum into view. In many cases, the dilated stomach was found just under the incised peritoneum. The greater curvature of the stomach was grasped with a moist sponge and the pylorus delivered by a gentle rocking movement (Fig. 3). All patients have variable degrees of fibrosis and scarring in the pylorus, which was contracted and rigid. Palpation reveals thickening in the gastric outlet region. Standard HMP was done. Between two traction sutures placed about 1 cm apart on the anterior surface of the pylorus, a longitudinal incision extending about 1–3 cm onto the antrum and a similar distance onto the duodenum. The incision was marked initially by diathermy needle (Fig. 4). The incision was created by fine tip needle diathermy for hemostasis. The total length of the incision ranged from 5 to 7 cm. The initial entry into the gut lumen was made in the duodenum due to pyloric scaring. The longitudinal incision was closed transversely by one layer of interrupted 4/0 coated VICRYL® (polyglactin 910) suture (Fig. 5). The suture line was covered by omentum. The midline fascia was closed by an interrupted 2/0 polyglactin suture (Fig. 6). Finally, the skin incision was closed by a subcuticular 4/0 Vicryl suture (Fig. 7). No abdominal drain was used.

Fig. 3

Delivery of the dilated stomach from the incision

Fig. 4

Marking the site of incision for pyloroplasty by needle diathermy

Fig. 5

The longitudinal incision was closed transversely by one layer interrupted suture

Fig. 6

Closure of facial incision

Fig. 7

Closure of the skin


The ages ranged from 17 months to 6 years with a median age of 3 years. The exact amount and concentration of the acid corrosive substance was not known.

The duration from ingestion to definitive surgery ranged from 2 to 6 months. The main symptoms were non-bilious vomiting, post-prandial abdominal distension, progressive weight loss, and constipation. Recurrent hematemesis occurred in two patients due to stasis gastritis and ulceration documented during upper gastrointestinal endoscopy.

Preoperative upper gastrointestinal (GIT) contrast study revealed variable degrees of gastric dilatation, pyloric stricture with delayed evacuation of the contrast material. Upper GIT endoscopy confirmed the diagnosis and attempts to dilate the stricture made whenever possible. Six patients were referred with recurrence of the pyloric stricture after repeated endoscopic trials. One patient developed both esophageal and pyloric stricture; the esophageal stricture responded to repeated endoscopic dilatation while the pyloric stricture failed to respond to the repeated endoscopic dilatation. Four patients were referred for surgical intervention after the first unsuccessful endoscopic dilatation trial due to tight pyloric stricture.

Operative results

Delivery of the stomach and pylorus through the circum-umblical incision was successful in 10 patients. Longitudinal extension of the skin incision was needed in one patient due to difficulty in delivery of a hugely thickened stomach. The pylorus was grossly affected in 9 patients while both the pylorus and the gastric antrum were involved in 2 patients.

The HMP was feasible in all patients. The operating time ranged from 60 to 90 min (median 80 min). The postoperative hospital stay was ranged from 5 to 7 days. Oral clear fluids were started on the second postoperative day. The vomiting stopped in 10 patients, who started to gain weight. The wound healed primarily without wound infection, wound dehiscence, or incisional hernia.

One patient had a failure to gain weight with recurrent vomiting. Upper GIT endoscopy revealed recurrent pyloric stricture after 2 months. Gastrojejunostomy was done through a right upper transverse abdominal incision. The patient discharged from the hospital after 7 days. Follow-up for 1 year showed no recurrence of symptoms.

All patients were followed-up from 3 months to 7 years with a mean of 3.1 years. In all patients, the circum-umblical incision left an almost undetectable scar and integrating well with the natural umbilical skin folds.


Acid corrosive ingestion usually leads to gastric injury and pyloric stenosis [4, 7, 8, 21]. Acids lead to coagulative necrosis of the pyloric region with subsequent segmental or extensive stricture formation while alkalis produce penetrating or liquifactive necrosis mainly in the oesophagus [22]. Acid is more likely than alkali to produce gastric injury [23]. Consequently, surgical intervention for gastric lesion is usually needed [24].

There are still some controversy regarding the appropriate timing and selection of surgical techniques. Previous studies have recommended pyloroplasty or gastrojejunostomy through exploratory incision, based on the location and extent of gastric injury [4, 7, 21, 25].

Since the seminal description of circum-umbilical approach by Tan and Bianchi in 1986 [11], the transumbilical approach was used for various intra-abdominal disorders of neonates, infants, and children due to elasticity of the abdominal wall [19, 20].

We have reported the versatility of transumbilical approach for management of various abdominal pathology in infants [15, 16]. Our hypothesis was that such approach may be feasible in children with GOO following acid corrosive ingestion. In addition to the expected excellent cosmetic results, it could avoid the potential complications of wound healing after conventional upper transverse abdominal incision in this vulnerable group of nutritionally depleted children. To test this hypothesis, the current prospective study was planned.

We were concerned about two specific issues: [1] the feasibility of delivering, and returning back the dilated stomach and scarred pylorus through this incision in older children; and [2] the feasibility, safety, and efficacy of HMP in relieving of GOO when scaring is not limited to pylorus. In extensive fibrosis, we use another technique as finney pyloroplasty.

We found that the thin abdominal wall due to recent loss of weight with subsequent loss of subcutaneous fat, the semicircular skin incision, and the extended midline incision of the fascia have facilitated the delivery of pylorus through the cirum-umblical incision even in older children. This incision was feasible in all cases except one patient, who required further vertical extension of skin incision.

The current study showed also the feasibility and efficacy HMP as a surgical treatment of GOO in this group of patients. The longitudinal incision should be extended proximal to the scarred pyloric canal leading to a wide HMP.

It seems that HMP may not be the appropriate technique in cases of pyloric stricture with proximal extension of the scaring into the antrum. One of the two patients with antral scaring required redo surgery (gastrojejunostomy).

To the best of our knowledge, this is the first description of transumbilical pyloroplasty in the management of post-acid corrosive gastric outlet obstruction in children. Many publications have proven the lower risk of wound dehiscence after transumbilical pyloromyotomy for the management of hypertrophic pyloric stenosis in infants, even in those patients, who were nutritionally deprived due to prolonged vomiting [11,12,13]. Likewise, the feasibility and safety of this approach in the management of Hirschsprung’s disease, ovarian cysts, and many other abdominal conditions have been reported, both in infants and older children [14,15,16,17,18,19,20].

The pyloroplasty has been conventionally performed through laparotomy incision. El-Asmar and Allam reported 26 patients with corrosive-induced gastric injury treated with different surgical techniques, postoperative anastomotic stricture requiring a second operation developed in one patient. Three deaths related to the associated esophageal strictures were reported in their series [10]. Ozokutan et al. reported 20 patients with GOO over 8 years; pyloroplasty was done in 5 patients, anastomotic stricture requiring a second operation developed in two of the 20 patients. There was no surgical mortality [21]. Ciftci et al. reported 11 patients with gastric outlet obstruction; pyloroplasty was done in 2 patients with no postoperative complications [4]. In the current study, recurrent stricture developed in one patient, no mortalities occurred.

None of the previously published articles has focused on the abdominal wound [4,5,6,7,8,9,10] to enable us to compare objectively between trans-umbilical vs the conventional laparotomy approach in terms of abdominal wound healing and its potential complications. However, based on the results of the current study, it seems that one of the main advantages of this technique is minimizing the incidence of wound dehiscence, which may be a real risk after surgery for nutritionally debilitated children with gastric outlet obstruction.

One of the attractive alternatives to the current transumblical approach is laparoscopy. Recently, Seleim et al. [26] reported laparoscopic diamond antroduodenostomy in 5 patients with GOO as a consequence of caustic liquid ingestions. The average operative time in the laparoscopic group is comparable to the current transumbilcal study (81 vs 80 minuses). No anastomotic leak occurred in both studies. However, postoperative delayed gastric emptying was noted in 2 cases in laparoscopic-treated group. A comparable postoperative hospital stay 5–7 days was noted. This shows that the current transumbilical approach is an attractive minimal invasive approach compared to laparoscopy in the absence of required facilities and expertise to conduct laparoscopy safety in this group of patients.

The results of HMP through the circum-umblical approach are quite encouraging. However, the small numbers of patients and the lack of control group represent limitations of the current study. Future studies with larger numbers of patients are recommended.

Heinecke-Mikulicz pyloroplasty through a circum-umbilical approach is feasible and safe in the majority of children with post-acid corrosive GOO. It is associated with satisfactory wound healing and excellent cosmetic outcome. The cosmetic and functional results compare favorably or surpass conventional laparotomy or laparoscopy for pyloroplasty.
